Ceramic testing equipment to measure the Dynamic Coefficient of Friction of flooring surfaces. According the Standards DIN 51130, DIN 51097 and ISO 10545-17 Annex C and the Australian Standard

The DIN Ramp Tester comprises of a frame to which is fitted a movable ramp. There is a water reservoir which enables the surface under test to have a constant flow of recycled water The frame is also fitted with a harness which is used to ensure the safety of the tester
Before the test, the surface to be tested (minimum 100 x 50 cm) and the operator's feet and or shoes are lubricated. The operator, faces "downhill", and moves backwards and forwards with steps that are as long as the length of the shoe. The ramp slipperiness meter will increase the angle at a rate of no more than 1° per second. (the Standard suggests the use of a metronome to control pace)
The angle in which the operator reaches the limit of security is noted. The critical angle is determined by averaging several tests, by two operators
Features
· inclinable platform from 0° up to 45° (600 x 2000 mm) driven by an hydraulic cylinder
· Water circulating pump that is requested just to test surfaces according to the 51097 DIN
· supplied with handrail and safety sling
· maximum speed of inclination of 1°/s
· inclinometer with accuracy of ±0,1° for the determination of safety critical angle
· 400 V, 50/60 Hz, three phases, 850 W
Equipment
· inclinometer
· mobile control panel controlled by the operator
· water recirculation pump to execute tests according to the DIN 51097 Standard
· safety harness K4 CEEN 385 with rope for harness FP CEN 35

Dimensions: 2750x1350x3750 mm
Weight: 290 kg

IT SHOULD BE NOTED that the Standardisation Panels are designed to give a consistent result where different testers use the equipment in accordance with the DIN and Australian Standard. They DO NOT calibrate the instrument

Alternative methods for measuring skid resistance
The Pendulum Skid Tester
The Pull Meter
Tortus 3

When buying this item you may also be interested in a Surface Roughness Meter - requires as part of the ISO test

RAMP SLIPPERINESS METER for the ceramic testing standard DIN 51130

ACCESSORIES
Pair of shoes size 42 Picasso type with sole hardness shore-a 72 ±2 and engraving according the standard DIN 51130 to make testings using the ramp slipperiness meter.
STANDARDISATION PANEL TYPE E-10,7°
Reference tile panel type E - 10,7° to calibrate the ramp slipperiness meter C03463 according the Standard DIN 51130. Panel dimensions approx 1.000 x 500 mm with tiles 152x152x10 mm.
STANDARDISATION PANEL TYPE P-18,2°
Reference tile panel type P-18,2° to calibrate the ramp slipperiness meter C03463 according the Standard DIN 51130. Panel dimensions approx 1.000 x 500 mm with tiles 151x151x12 mm.
CALIBRATION PANEL TYPE R-26,8°
Reference tile panel type R - 26,8° to calibrate the ramp slipperiness meter C03463 according the Standard DIN 51130. Panel dimensions approx 1.000 x 500 mm with tiles 151x151x12 mm.
STANDARDISATION "A" DIN 51097
Reference tile panel type A to calibrate the ramp slipperiness meter C03463 according the Standard DIN 51097. Panel dimensions approx 1.000 x 500 mm with tiles 242x117x11 mm
STANDARDISATION "B" DIN 51097
Reference tile panel type B to calibrate the ramp slipperiness meter C03463 according the Standard DIN 51097. Panel dimensions approx 1.000 x 500 mm with tiles 241x117x11,5 mm
STANDARDISATION "C" DIN 51097
Reference tile panel type C to calibrate the ramp slipperiness meter C03463 according the Standard DIN 51097. Panel dimensions approx 1.000 x 500 mm with tiles 149x149x11 m
